Features:
1. The new universal glow head driver, both manual and remote control can be controlled;
2. Industrial grade isolation design, can be directly connected to 380 motors;
3. Alligator head clip design, convenient and quick wiring;
4. With a switch indicator, the working status of the driver is clear at a glance;
5. Transparent heat shrinkable tube packaging, the indicator status is clear at a glance, light weight and small size;
6. Input power supply voltage of motor and glow head 4.5V~20V, wide voltage design. Recommend 12V/3S power supply;
7. The receiver can support high-voltage receivers, 5V~12V receivers can be connected, and the signals are fully compatible;
8. The glow head output has overcurrent protection and overheat protection.
Description:
-This controller does not have low voltage protection, please pay attention to the battery power during use. (It is recommended to use 3s lithium battery alone for power supply).
-The input voltage of the glow head controller is 4.5V-20V, the output voltage of the glow head is 1.3V3A, the output voltage of the motor terminal is equal to the supply voltage, and the continuous current is 5A.
-The controllers have remote control mode and one-key start mode respectively.
-Through the receiver signal control and button control. Remote control has priority.
-Receiver remote start mode (usually controlled by two-stage switch channel) triggers from low to high to enter start mode, and the blue indicator light is on indicate that it is working. It will automatically turn off after 3 seconds (the time can be adjusted in 1, 2, 3, 4 seconds).
-One-key start-up mode: Short press the button once, the controller enters the start-up mode, the blue indicator light is on, and it will automatically turn off after 3 seconds (the time is adjustable in 1, 2, 3, 4 seconds).
Package included:
1pcs x ignitor
